Коммутатор Cisco Nexus N9K-C9372TX-E
Прямой импорт оборудованияиз Китая и ОАЭ без посредников
Почему нет цен?
Уточнить цену
Гарантия до 5 лет
Диагностика перед отправкой
С нами выгодно и удобно!
- Поддержка персонального менеджера
- Возмещение НДС до 20%
- Онлайн-кабинет гарантийного сервиса
Как купить?
Раз, два и все делаРассчитаем стоимость
Присылайте спецификацию для подбора и расчета стоимости оборудования
Привезём и подключим
Подключим и настроим оборудование в вашем офисе или ЦОДе
Характеристики
Отсрочка платежа
В зависимости от суммы поставляемого товара можем предоставить отсрочку платежа на срок от 5 до 90 дней. Условия отсрочки платежа рассматриваются индивидуально. Подробную информацию уточняйте у вашего менеджера.
Первый платеж
Второй платеж
Первый платеж
Второй платеж
Первый платеж
Второй платеж
Описание
The Cisco Nexus 9372TX-E Switch (N9K-C9372TX-E) is a minor hardware revision of the Cisco Nexus 9372TX. Enhancements include hardware capability for IP-based EPG classification in Cisco ACI mode.
Quick Specs
Figure 1 shows the appearance of the N9K-C9372TX-E.
Table 1 shows the Quick Specs.
| Product Code | N9K-C9372TX-E |
| Ports | 48 fixed 1/10GBASE-T and 6 QSFP+ ports |
| Form factor | 1 RU |
| Throughput (Tbps) | 1.44 |
| Supported speeds | 100 Megabit Ethernet and 1/10 Gigabit Ethernet speeds |
| 40 Gigabit Ethernet uplink port | 6 fixed QSFP+ ports ·Advanced QSFP+ optics enable connectivity using existing 10 Gigabit Ethernet fiber.·The switch offers 25 MB of additional packet buffer space shared with all ports for more resilient operations |
| Power supplies (up to 2) | 650W AC, 930W DC, or 1200W HVAC/HVDC |
| Typical power(AC & DC) | 374.5W |
| Maximum power(AC & DC) | 694W |
| Maximum number of longest prefix match (LPM) routes | 128,000 |
| CPU, SSD, and memory | Dual-core 2.5-GHz x86 CPUs with 64-GB SSD drive and 16 GB of memory provide enhanced network performance |
| Buffer (MB) | 37 |
| Operating System | NX-OS, ACI |
| Fans | 4 |
| Physical (H x W x D) | 1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1cm) |
| Acoustics | 48.6 dBA at 40% fan speed, 65.2 dBA at 70% fan speed, and 76.5 dB at 100% fan speed |
| Weight?without power supplies or fans? | 22.6 lb (10.25 kg) |
·Typical and maximum power values are based on input drawn from the power circuit. The power supply value (for example, 650W AC power supply: N9K-PAC-650W) is based on the output rating to the inside of the switch.
·The actual maximum scale depends on the system forwarding mode
Product Details
Figure 2 shows the front panel of the N9K-C9372TX-E.
Note:
| ? | Beacon (BCN), Status (STS), and Environment (ENV) LEDs |
| ? | 10GBASE-T APIC-facing ports (48) supporting 100-Megabit, 1-Gigabit, and 10-Gigabit Ethernet |
| ? | 40-Gigabit QSFP+ spine-facing ports (6) supporting 10- and 40-Gigabit Ethernet |
The Accessories
Table 2 shows the recommended elements for the the N9K-C9372TX-E.
| Category | Model | Description |
| 40G Transceiver and Cable Options
| Cisco QSFP to QSFP copper direct-attach 40GBASE-CR4 cable QSFP-H40G-ACU10M | |
| Cisco QSFP to QSFP copper direct-attach 40GBASE-CR4 cable QSFP-H40G-CU1M | ||
| Cisco QSFP to QSFP copper direct-attach 40GBASE-CR4 cable QSFP-H40G-CU3M | ||
| Cisco QSFP to QSFP copper direct-attach 40GBASE-CR4 cable QSFP-H40G-CU5M |
Compare to Similar Items
Table 3 shows the comparison of the N9K-C9372TX-E and N9K-C9372PX-E.
| Product Code | N9K-C9372TX-E | |
| Ports | 48 fixed 1/10GBASE-T and 6 QSFP+ ports | 48 fixed 1/10GBASE-T and 6 QSFP+ ports |
| Form factor | 1 RU | 1 RU |
| Throughput (Tbps) | 1.44 | 1.44 |
| Supported speeds | 100 Megabit Ethernet and 1/10 Gigabit Ethernet speeds | 1/10 Gigabit Ethernet speeds |
| Typical power(AC & DC) | 374.5W | 210W |
| Maximum power(AC & DC) | 694W | 537W |
| Maximum number of longest prefix match (LPM) routes | 128,000 | 128,000 |
| Acoustics | 48.6 dBA at 40% fan speed, 65.2 dBA at 70% fan speed, and 76.5 dB at 100% fan speed | 48.5 dBA at 40% fan speed, 64.9 dBA at 70% fan speed, and 77.8 dB at 100% fan speed |
| Weight?without power supplies or fans? | 22.6 lb (10.25 kg) | 22.2 lb (10.1 kg) |
Do you have any question about the the N9K-C9372TX-E?
